ZS 110 CC 4 SPEED ENGINE KICK START MANUAL CLUCTH
IDR. 6.000.000
ZS 110 CC 4 SPEED ENGINE KICK START
MANUAL CLUCTH
SPECIFICATION
Engine type : 1-cylinder, 4-stroke,air-cooled,
camshaft downward
Displacement (ml) : 113.3
Dimension (mm x mm x mm) : 455× 280 × 230
Net weight (kg) : 16.5
Max.Power (kw/r/min) : 7.2(1±10%)/9500(1±5%)
Max.Torque (N.m/r/min) : 8(1±10%)/8500 (1±5%)
Compression ratio : 11.5:1
Bore and Stroke (mmxmm ) : 54x49.5
Ignition methode : CDI
Lubrication methode : Pressure and splash
Min.Fuel Consumption (Kw.h) : =367
Starting methode Kick
Clutch methode Manual Wet Multi-Plate
Gearshift methode Constant mesh,
two stage transmission, 4-speed Gearshif
